1.2.1. Output power
The power supply units supply a direct-current voltage of 16 V.
The following table shows the maximum permitted output current:
Power supply unit I
max
SKZ 5-01 10 A
SKZ 5-03 4.5 A
SKZ 5-04 2 x 10 A
SKS 6-00 18 A
It is imperative to use a power supply unit with sufficient output power for your application!
1.2.2. Supply of the cassettes
The following combinations are possible:
Base unit
Power
supply unit
SKS 4-01 SKS 40-00 SKS 8-00 Without
SKZ 5-01 Max. 4x SKP x-xx
Max. 4x SKT 2-0x
Max. 4x SKM x-xx
Max. 4x SKx 40-0x
Max. 3x SKx 80-0x
Max. 4x SKP x-xx
Max. 4x SKT 2-0x
Max. 4x SKM x-xx
Max. 4x SKx 40-0x
Max. 3x SKx 80-0x
SKZ 5-03 Max. 2x SKP x-xx
Max. 2x SKT 2-0x
Max. 2x SKM x-xx
Max. 2x SKx 40-0x
Max. 1x SKx 80-0x
SKZ 5-04 Max. 4x SKx 40-0x
Max. 4x SKx 80-0x
Max. 4x SKx 40-0x
Max. 4x SKx 80-0x
SKZ 6-00 Max. 8x SKP x-xx
Max. 8x SKT 2-0x
Max. 8x SKM x-xx
Max. 8x SKx 40-0x
Max. 5x SKx 80-0x
