3. Installation and commissioning
 Installation must be performed by authorized and skilled electricians only.
 Switch off the operating voltage or pull out the mains plug.
 Installation of the device must be performed in compliance with the safety regulations defined by the
EN 60728-11 standard. Connect the device with an equipotential bonding cable (copper, minimum 4 mm²).
Mount the power supply unit according to the instructions given in chapter 2.
Connect the power supply unit as described in the operating instructions for the base unit or, in case of external
installation, according to the operating instructions for the cassette.
For connection of cassettes with barrel connectors, an adapter is supplied for power supply units equipped with
high-current connectors.
Make sure that the mains voltage is within the permitted range and connect the power supply unit.
4. Technical data
SKZ 5-01 SKZ 5-04 SKZ 6-00 SKZ 5-03
Input voltage 100…240 V~ / 50-60 Hz
Input voltage
Output power 16 V / 10 A 16 V / 2 × 10 A 16 V / 18 A 16 V / 4.5 A
Connection High-current connector with adapter Barrel connector
For base unit – SKS 40-00
SKS 4-01
SKS 8-00
Ambient temperature range
(according to EN 60065) -10°C…+50°C
Protection class IP 20
