AXING SPU 81-0x - Handbuch (Seite 3)

State of the art 2015-05-21 - Reserving change in design and type -
We cannot be held liable for printing errors Manufacturer
AXING AG
Gewerbehaus Moskau
CH-8262 Ramsen EWR contact adress
Bechler GmbH
Am Rebberg 44
D-78239 Rielasingen
Safety advice:
· Installation and repairs to the equipment may only be carried out by
technicians observing the current VDE guidelines. No liability will be
assumed in the case of faulty installation and commissioning.
· To prevent damage to your equipment and to avoid possible peripheral
damages, the devices foreseen for wall mounting may only be installed
on a flat surface.
· Choose the location of installation or mounting such that children may
not play unsupervised near the equipment and its connections. The
location of installation or mounting must allow a safe installation of all
cables connected. The mains cable as well as feeder lines may not be
damaged or clamped by objects of any kind.
· Choose the location of installation or mounting so that under no
circumstances liquids or objects can get into the equipment (e.g.
condensation, water coming from leaking roofs or flowing water, etc.).
· Avoid exposure of the equipment to direct sunlight and to other heat
sources (e. g. radiators. other electrical devices, chimney, etc.). Absolutely
avoid that cables come near any source of heat (e.g. radioators, other
electrical devices, chimney, etc.).
Technical Data:
SPU 81-00 SPU 81-02
Frequency range SAT 950…2200 MHz
Inputs 8 2 × 8
Outputs 1 1
Through loss typ. 2,5 dB
Isolation 30 dB ³
Switching criteria Position + Option + Uncommitted_1
DiSEqC 1.2 "drive to position x" (6Bh)
Connectors F
Dim. appr. 150 × 110 × 30 155 × 110 × 50
SPU 81-00 | SPU 81-02
8 in 1 | 2 × 8 in 1
DiSEqC switches
Operation Instructions
This symbol indicates that this product is not to be disposed of with your
household waste, according to the WEEE Directive (2002/96/EC) and your
national law.
This product should be handed over to a designated collection point, e.g.,
on an authorized one-for-one basis when you buy a new similar product or
to an authorized collection site for recycling waste electrical and electronic
equipment (WEEE).
For more information about where you can drop off your waste equipment
for recycling, please contact your local city office, waste authority, approved
WEEE scheme or your household waste disposal service.
WEEE Nr.
DE14023300
