Technische Daten
Frequenzgang J-INFRA,
Standard und 70-Hz-Schaltung
J-INFRA Systemdaten
Frequenzgang (–5 dB Standard)...........................................................27 Hz ... 60 Hz
Frequenzgang (–5 dB 70-Hz-Modus)..................................................27 Hz ... 70 Hz
Maximaler Schalldruck (1 m, Freifeld)
mit D12......................................................................................................................141 dB
mit D80......................................................................................................................144 dB
(SPLmax peak mit Musikprogramm)
J-INFRA Lautsprecher
Nennimpedanz.....................................................................................................3/6 Ohm
Belastbarkeit LF-Front (RMS / peak 10 ms)........................................1200/4800 W
Belastbarkeit LF-Rear (RMS / peak 10 ms)..........................................600/2400 W
Komponenten..................................................................................3 x 21”-Lautsprecher
Anschluss....................................................................................................................1 x EP5
.................................................................................................................(optional 1 x NL8)
Belegung
NLT4F..................................................1+: Front+/1–: Front–/2+: Rear+/2–: Rear–
EP5.............................1: Front+/2: Front–/3: Rear+/4: Rear–/5: SenseDrive front
NL8..............1+: Front+/1–: Front–/4+: Rear+/4–: Rear–/3–: SenseDrive front
Gewicht........................................................................................................................................152 kg
Gehäuseabmessungen J-INFRA in mm [Zoll]
