BECKHOFF CB4055 Benutzerhandbuch
Seite 22
Kapitel: Anschlüsse
PCI/104-Express-Bus
Seite 22
Beckhoff New Automation Technology CB4055
Beschreibung
Name
Pin
Name
Beschreibung
Masse
GND
55
56
GND
Masse
x16 Transmit Lane 8 +
PE16T8
57
58
PE16T0
x16 Transmit Lane 0 +
x16 Transmit Lane 8 -
PE16T8#
59
60
PE16T0#
x16 Transmit Lane 0 -
Masse
GND
61
62
GND
Masse
x16 Transmit Lane 9 +
PE16T9
63
64
PE16T1
x16 Transmit Lane 1 +
x16 Transmit Lane 9 -
PE16T9#
65
66
PE16T1#
x16 Transmit Lane 1 -
Masse
GND
67
68
GND
Masse
x16 Transmit Lane 10 +
PE16T10
69
70
PE16T2
x16 Transmit Lane 2 +
x16 Transmit Lane 10 -
PE16T10#
71
72
PE16T2#
x16 Transmit Lane 2 -
Masse
GND
73
74
GND
Masse
x16 Transmit Lane 11 +
PE16T11
75
76
PE16T3
x16 Transmit Lane 3 +
x16 Transmit Lane 11 -
PE16T11#
77
78
PE16T3#
x16 Transmit Lane 3 -
Masse
GND
79
80
GND
Masse
x16 Transmit Lane 12 +
PE16T12
81
82
PE16T4
x16 Transmit Lane 4 +
x16 Transmit Lane 12 -
PE16T12#
83
84
PE16T4#
x16 Transmit Lane 4 -
Masse
GND
85
86
GND
Masse
x16 Transmit Lane 13 +
PE16T13
87
88
PE16T5
x16 Transmit Lane 5 +
x16 Transmit Lane 13 -
PE16T13#
89
90
PE16T5#
x16 Transmit Lane 5 -
Masse
GND
91
92
GND
Masse
x16 Transmit Lane 14 +
PE16T14
93
94
PE16T6
x16 Transmit Lane 6 +
x16 Transmit Lane 14 -
PE16T14#
95
96
PE16T6#
x16 Transmit Lane 6 -
Masse
GND
97
98
GND
Masse
x16 Transmit Lane 15 +
PE16T15
99
100
PE16T7
x16 Transmit Lane 7 +
x16 Transmit Lane 15 -
PE16T15#
101
102
PE16T7#
x16 Transmit Lane 7 -
Masse
GND
103
104
GND
Masse
SDVO Data
SDVODAT
105
106
SDVOCLK
SDVO Clock
Masse
GND
107
108
GND
Masse
x16 Receive Lane 8 +
PE16R8
109
110
PE16R0
x16 Receive Lane 0 +
x16 Receive Lane 8 -
PE16R8#
111
112
PE16R0#
x16 Receive Lane 0 -
Masse
GND
113
114
GND
Masse
x16 Receive Lane 9 +
PE16R9
115
116
PE16R1
x16 Receive Lane 1 +
x16 Receive Lane 9 -
PE16R9#
117
118
PE16R1#
x16 Receive Lane 1 -
Masse
GND
119
120
GND
Masse
x16 Receive Lane 10 +
PE16R10
121
122
PE16R2
x16 Receive Lane 2 +
x16 Receive Lane 10 -
PE16R10#
123
124
PE16R2#
x16 Receive Lane 2 -
Masse
GND
125
126
GND
Masse
x16 Receive Lane 11 +
PE16R11
127
128
PE16R3
x16 Receive Lane 3 +
x16 Receive Lane 11 -
PE16R11#
129
130
PE16R3#
x16 Receive Lane 3 -
Masse
GND
131
132
GND
Masse
x16 Receive Lane 12 +
PE16R12
133
134
PE16R4
x16 Receive Lane 4 +
x16 Receive Lane 12 -
PE16R12#
135
136
PE16R4#
x16 Receive Lane 4 -
Masse
GND
137
138
GND
Masse
x16 Receive Lane 13 +
PE16R13
139
140
PE16R5
x16 Receive Lane 5 +
x16 Receive Lane 13 -
PE16R13#
141
142
PE16R5#
x16 Receive Lane 5 -
Masse
GND
143
144
GND
Masse
x16 Receive Lane 14 +
PE16R14
145
146
PE16R6
x16 Receive Lane 6 +
x16 Receive Lane 14 -
PE16R14#
147
148
PE16R6#
x16 Receive Lane 6 -
Masse
GND
149
150
GND
Masse
x16 Receive Lane 15 +
PE16R15
151
152
PE16R7
x16 Receive Lane 7 +
x16 Receive Lane 15 -
PE16R15#
153
154
PE16R7#
x16 Receive Lane 7 -
Masse
GND
155
156
GND
Masse
Versorgungsspannung 5V
VCC
C1
Versorgungsspannung 5V
VCC
C2
Versorgungsspannung 12V
12V
C3
