Operation
G&D RackConsole 17 · 4
Operation
How to operate the TFT drawer:
1. Use the handle to pull the drawer out of the rack.
2. Lift the display to activate it.
3. If necessary, press the device’s
Power
button (see image 6 on page 3).
4. Set any resolution up to
1280 × 1024 @ 60 Hz
.
5. After operation close the display, and slide the drawer back into the rack.
NOTE:
When using both video inputs (DVI and VGA), press the
Source
button
to switch between digital and analogue input.
Press the
Auto
button for auto adjusting the analogue signal.
