JB-Lighting Varyscan P2 250 HTI - Handbuch (Seite 19)

1.3 Technical data
weight: 21 kg
Power connection: 230 V 50 Hz
Power consumtion: 2,1 A
light source: OSRAM Baby-SharXS
HTI 250W
max.
ambient temperature: 40°C
1. Indroduction
1.1 General Remarks
The Varyscan P2 250 HTI is equipped with 7 colours plus white, one colour effect
wheel with progressive frost filter, CTO- and CTB-filter, pink, cyan, 1 x 5 gobos
(rotating, indexable and interchangeable), focus, one rotating, indexable and
exchangeable prism, dimmer and shutter.
The pan and tilt movement can opperate in 8bit or 16bit mode, depending on
the lighting control desk in use.
1.2 Unpacking
Open the top of the box and remove the inlays. Remove the unit from the box.
For any damage occuring during transport, report to the transport company
immediately.
WARNING: This device is for professional use only!
!
301
385
389
422 469
320
8
124
362
197
559
XLR-connector
base
arm
head
control panel
power supply
2
480 VA
20
