Reset DMX values of a step:
To reset the DMX values of a step proceed as follows:
Press key MENU one time. Then press 5 times key +
S
will be shown on the display TANDALONE STEPS
Confirm by pressing key ENTER.
STEP NR. 1/X will be displayed. Recall the desired step by means of the keys "+ -"
and confirm the selection by pressing key ENTER.
Select function
by means of the keys "+ -" RESET STEP
After selecting the function press key ENTER.
SURE? will be displayed. Confirm selection by pressing key ENTER again.
The DMX values of the selected step will be set to zero.
Store cues from a DMX board:
Select the Standalone menu.:
Press key MENU first and then press key + five times.
will be displayed. Confirm selection by pressing key ENTER.
Then press key + one time to enter capture function.
will be displayed. Press ENTER to enable the fixture to receive DMX
data from a connected DMX board. The display will show
To store data press ENTER again.
The display will show:
To insert a new step press key +
The display will show:
Press ENTER to confirm and the display will show:
To continue programming press key - one time and find:
shown on the display.
Press ENTER to enable fixture to receive DMX data,
will be
displayed.
Repeat the process of storing data on the fixture by pressing ENTER again.
(Press enter first time:
;
Press enter second time:
To continue, insert a new step and repeat process.
STANDALONE STEPS
CAPT DMX 1/ 1
DMX CAPTURE.
CAPT DMX 1/1
SURE?
INSERT 2/2
CAPT DMX 2/2
DMX CAPTURE
START CAPTURE
CAPT DMX X / X)
