Stückliste Varyscan 6 Effekt Stückliste Varyscan 6 Effekt--Platine Platine
C1 1N
C2 1N
C3 1N
C4 1N
C5 1N
C6 820P
C7 820P
C8 820P
C9 820P
C10 820P
C11 820P
C12 820P
C13 820P
C14 820P
C15 820P
C16 3N3
C17 3N3
C18 3N3
C19 3N3
C20 3N3
C21 100N
C23 100N
C24 100N
C25 100N
C26 100N
C27 100N
C29 100N
C30 100N
C31 100N
C32 100N
C33 100N
C34 100N
C35 100N
C36 100N
C37 100N
C38 100N
C39 100N
C40 100N
C41 100N
C42 100N
C43 100N
C44 2200U/16
C45 10U/16
C46 47U/25
C47 47U/25
C48 47U/25
C49 220U/35
C50 220U/35
C52 220U/35
C53 220U/35
D1 LM336LP
D2 SA5_0CARL
IC1 68HC11F1
IC2 27C256
IC3 ADM709LAN
IC4 74HCT138
IC5 AM26LS32
IC6 PBM3960
IC7 PBM3960
IC8 PBM3960
IC9 PBM3960
IC10 PBM3960
IC11 PBL3771
IC12 PBL3771
IC13 PBL3771
IC14 PBL3771
IC15 PBL3771
JP1 AMP1
JP2 AMP1
JP3 AMP1
JP4 AMPQ2
JP5 AMPQ2
JP6 DB15F
JP7 DB15F
JP8 AMPQ4
JP9 AMPQ4
JP10 AMPQ4
Q1 BC337-25
Q2 BC337-25
R1 10K
R2 1K
R3 10K
R4 470
R5 470
R6 3R9
R7 15K
R8 15K
R9 15K
R10 15K
R11 15K
R12 1K
R13 1K
R14 1K
R15 1K
R16 1K
R17 1K
R18 1K
R19 1K
R20 1K
R21 1K
R22 0R68
R23 0R68
R24 0R68
R25 0R68
R26 0R68
R27 0R68
R28 0R82
R29 0R82
R30 1R
R31 1R
R32 0R68
R33 470R
R34 3R9
R35 10K
R36 10K
Y1 YO16M
