Vorderseite
Lesen Sie hinsichtlich der hier nicht erklärten Tasten die in Klammern ( ) angegeben Seiten.
q
e r
y
t
u
Q3
w
Q8
Q7
Q4
Q9
Q5
Q6
o
i
Q1
Q0
Q2
q
STANDBY-Anzeige ·································································· (
GSTANDBY-AnzeigestatusH
• Eingeschaltet : Aus
• Normales Standby: Rot
• Wenn “HDMI Steuerung” (
) auf “Ein” eingestellt
ist: Orange
w
Netzschalter (
X ON/STANDBY) ············································· (
Schaltet das Gerät ein und aus (Standby).
e
Kopfhörerbuchse (PHONES)
Wenn an dieser Buchse Kopfhörer angeschlossen werden, wird
über die angeschlossenen Lautsprecher kein Ton ausgegeben.
HINWEIS
Zur Vermeidung von Gehörschäden sollte die Lautstärke nicht
übermäßig hoch eingestellt werden.
Q3
VOLUME-Knopf ······································································· (
)
Q4
PURE DIRECT-Anzeige ···························································· (
)
Q5
Hauptlautstärkeanzeige
Q6
Display ······················································································ (
)
Q7
Fernbedienungssensor ··························································· (
)
Q8
M-DAX-Anzeige ······································································· (
)
Q9
INPUT SELECTOR-Knopf ························································ (
)
r
SETUP MIC-Buchse ································································· (
)
t
M-DAX-Taste ··········································································· (
)
y
SLEEP-Taste ············································································· (
)
u
Tasten für gespeicherte Radiosender (PRESET CH +, –) ······ (
)
i
DISPLAY-Taste ········································································· (
)
o
STATUS-Taste ········································································· (
)
Q0
SOUND MODE-Taste ······························································ (
)
Q1
PURE DIRECT-Taste ································································ (
)
Q2
AUX-HDMI-Anschluss ····························································· (
)
