8 9
DEUTSCH
ENGLISH
10. In der Anzeige Ihres Bluetooth Gerätes wird nun „quadral RONDO“ erscheinen und
wenn Sie dieses Gerät dort bestätigen, erfolgt die dauerhafte Verbindung und die
Anzeige Ihrer RONDO aktiv wird kontinuierlich Grün leuchten.
11. Veränderungen in der Lautstärke können an Ihrem Gerät (Smartphone oder PC) und
über den ON/OFF Multi- Funktion - Knopf (1) auf der Gerätefront erfolgen.
Hinweis:
Ihre RONDO aktiv benötigt für die Kopplung keine PIN-Code Eingabe wenn Ihr
Smartphone oder PC den BT-Standard v2.1 oder Neuer beherrscht. Versionen v2.0 oder
älter benötigen für die Kopplung (pairing) die PIN-Code Eingabe „0000“.
Es kann immer nur ein Gerät zeitgleich mit Ihrer RONDO aktiv verbunden sein.
Technische Daten RONDO aktiv
Leistung 2 x 50 Watt
Harmonische Verzerrungen (Klirr) < 1 %
Frequenzgang 55Hz - 50.000Hz
Prinzip 2 Wege / Bassreflex
Eingänge
Analog RCA (Stereo)
Digital 1 x USB B
Bluetooth Ja
Ausgänge
Sub Out 3,5mm Mono Mini-Klinke
Mit geschalteten Hochpassfilter
Bestückung
Tieftöner pro Kanal 1 x 135 mm Titanium-PP
Hochtöner pro Kanal 1 x RiCom V
Abmessungen
H x B x T 280 x 150 x 215 mm
First of all we would like to thank you for your decision to purchase
our quadral RONDO active speaker. We manufacture top-quality audio
products that satisfy the requirements of lovers of “excellent sound
reproduction” and our equipment is far above the average. Even if you
already know a lot about this type of equipment, we will introduce some
basic rules in the following that will enable you to get the best out of
your new equipment.
Safety instructions
Please read through these instructions carefully and follow all of the steps listed here for
installing the equipment. You must abide by all of the warnings and safety instructions
that are stipulated on the unit and in this instruction manual. Keep this manual close to
hand so that you can consult it if you have any questions later on.
• The mains power cable and other connecting cables must be laid so that none of
them are crushed or damaged by furniture, are being trodden on, and / or that
nobody will trip over them.
• Take the power plug out of the socket during lightening storms or if the equipment will
not be used for a long time. Always pull the plug out of the socket and never remove
it by pulling on the cable!
• The amplifier‘s speaker terminals must only be connected up to the relevant inputs
on the speakers. You must never connect these terminals up to the electrical mains
supply (230V / 115V) as this will destroy the equipment and all interconnected units
immediately. Therefore you never fit plugs on these cable connections to ensure that
they can never be mixed up with mains plugs.
• Voltages above 30V can be present at the speaker terminals if high volume is being
used. Therefore you never touch the terminals when the amplifier is being used.
• Never use the equipment in the vicinity of water, in humid areas or outdoors.
Moisture can bypass the electrical insulation and this will create a life-threatening
The lightening symbol inside an
equal-sided triangle is used to
warn you about the presence
of non-insulated components
carrying a dangerous, live
voltage that might cause severe
personal injuries. The exclamation mark inside an
equal-sided triangle indicates that
there is important information
available regarding the use and
maintenance of your equipment.
