ENGLISH
risk as is the case with all equipment that has not been specially designed against the
penetration of moisture.
• Protect the equipment against water being sprayed on it. You must also ensure that
no vessels containing liquid (e.g. vases) are placed on top of the equipment.
• Do not place the equipment in the vicinity of a heat source such as an electric fire,
radiator, oven or similar.
• The slits and openings in the enclosure provide the ventilation and ensure reliable
operation. They must never be misaligned or covered.
• Burning-out of specific components cannot be completely excluded, despite the use of
protective devices, if the equipment is severely overloaded by continually using very
loud sound levels. A fire might also be caused inside the equipment in theory, as a
result of this type of overloading. Therefore the amplifier should always be used within
its limits and it should not be left unattended.
• Only our technical service should undertake the maintenance of your equipment.
Maintenance will be necessary if any type of damage occurs, i.e. if the power
cables or plugs are damaged, if an object falls on the equipment, if the equipment is
dropped or if liquid seeps into it. Never open the equipment as you might touch the
mains voltage (230V / 115V), which is dangerous.
• Only use furniture and other units for attaching and putting the equipment on that can
be obtained from or are recommended by the manufacturer. You must ensure that
moveable tabletop units or shelves on which the equipment will be placed are always
moved very carefully in order to prevent damage or injuries from being caused if the
equipment tips over.
• Continuously loud volume can damage your hearing!
• Only use a dry, soft cloth to clean your equipment.
• Keep the packing for possible transportation use later on and keep the plastic bag
well away from children, due to the risk of asphyxiation.
Positioning
Your new RONDO active speaker is suitable for use on a shelf or on your desktop. If you
are going to place it on your desktop, you should remove the metal feet at the bottom of
the speaker so that the speaker can be tilted for use. The layout shown here will optimise
the high tone reproductions in the seating position.
Front of the unit
1 ON/OFF: Multi-function control
a Turn to the left or right to decrease or increase the volume.
b Press the control in and hold it there for at least three seconds to activate the
switching ON or OFF system when it is in stand-by mode.
c Press the control once to activate ‘pairing’ when in Bluetooth mode. The display
LED (2) will then start to flash rapidly and your RONDO active speaker will send
a pairing code to your smart phone or PC to establish the link.
(See: Installing chapter)
2. The LED indicate the following operating modes:
Red = Standby (OFF mode)
Green = The unit is ready for use (ON mode)
Green flashes twice then stops = BT input is being selected
Green flashes rapidly = Bluetooth pairing function is working
RONDO
passive-speaker
RONDO
active-speaker
Monitor
Desk
1 2 3
