ACX-201 ABAX 4
Leistung des Netzteils ....................................................................................................... 1,2 A
Aufladestrom des Akkumulators .................................................................................... 350 mA
Belastbarkeit des Ausgangs AUX1 ................................................................................... 0,5 A
Belastbarkeit des Ausgangs AUX2 ................................................................................... 0,5 A
Belastbarkeit der Relaisausgänge ............................................................................... 1 A/24 V
Umweltklasse ........................................................................................................................... II
Betriebstemperaturbereich ................................................................................. -10 °C...+55 °C
Abmessungen der Platine ..................................................................................... 147 x 70 mm
Abmessungen des Gehäuses ..................................................................... 250 x 250 x 80 mm
Gewicht ............................................................................................................................. 130 g
DECLARATION OF CONFORMITY
Product:
ACX-201 – Expander of ABAX system hardwired
zones/outputs with power supply
Manufacturer:
SATEL spółka z o.o.
ul. Schuberta 79
80-
172 Gdańsk, POLSKA
tel. (+48) 0-58 320-94-00
fax. (+48) 0-58 320-94-01
Product description: Hardwired zone/output expander with power supply, designed to work
together with the ABAX wireless system controller within the 868.0MHz – 868.6MHz frequency
band, supplied from 18V DC power source. The device is intended to be used in intruder alarm
systems.
The product is in conformity with the following EU Directives:
R&TTE 1999/5/EC
The product meets the requirements of harmonized standards:
ETSI EN 300 220-1: v.2.1.1; ETSI EN 300 220-2: v.2.1.1
ETSI EN 301 489-1: v.1.6.1; EN 301 489-3: v.1.4.1
EN60950-1:2004
Notified entity participating in the conformity assessment :
Identification No.: 1471
Gdańsk, Poland 2007-11-26
Head of Test Laboratory:
Michał Konarski
The latest EC declaration of conformity and product approval certificates are available for
downloading on website www.satel.pl
SATEL sp. z o.o.
ul. Schuberta 79
80-
172 Gdańsk
POLEN
Fon: (+48) 58 320 94 00
[email protected]
www.satel.pl
