HEADPHONES: Just want to listen quietly? Connect your headphones here. The internal loudspeaker is
automatically switched off.
hen ‘on’ Indicates that power is connected to the unit and it is ready to go.
(Always switch off and disconnect the power cord when not in use).
REAR PANEL: Displays the model number, power requirements and serial number of the unit.
MAIN POWER LED: The led, w
MAIN POWER SWITCH: Main power switch for the unit.
POWER INLET SOCKET: Connect to your power source. Make sure the specified voltage is correct for
your country!
POWER FUSE: This is the main safety fuse for the unit. The fuse protects the AC power to the amplifier.
USE ONLY THE CORRECT SIZE AND RATING OF FUSE AS SPECIFIED ON THE PANEL. If a fuse blows or
fails and a replacement of the same size and rating is installed and it in turn blows, the amplifier has suffered a
malfunction internally and needs immediate service from a qualified technician. DO NOT TRY USING A FUSE
OF HIGHER RATING. Using a fuse that is too large in current rating may cause serious, irreparable damage to
the amplifier and presents a serious fire hazard. The mains fuse ratings are detailed in the specs section on page
7 of this manual.
LA20C
Power To The Music
L Z B 1 2 3 4
12
13
14
15
16
14 15 16
N15039
MAXIMUM POWER CONSUMPTION
30 WATTS 50/60Hz
SUPPLY VOLTAGE & FUSE RATING:
