8 9
(3) to inflate inner tubes with schrader valves
e.g. mountain bikes, trolleys and trailers.
(4) to inflate inner tubes with blitz valves,
e.g. city/trekking bicycles
(5) For inflating inner tubes with a presta valve, e.g. on racing bicy-
cles and mountain bikes.
(6) dual head (to lock in place, please fold down the lever at the
pump head.)
(valves not included)
inflating tyres with a schrader valve: (c2)
First remove the dust protection cap (1). insert the dual head with the
large opening into the valve (2). to lock in place, please fold down
the lever at the pump head (3).
inflating tyres with a blitz valve: (c3)
First remove the dust protection cap (1). insert the dual head with the
small opening into the valve (2). to lock in place, please fold down
the lever at the pump head (3).
inflating tyres with a presta valve: (c4)
First remove the dust protection cap (1). detach the valve nut (2a-2c).
insert the dual head with the small opening into the valve (3). to lock
in place, please fold down the lever at the pump head (4).
inflating air mattresses, inflatable toys, etc.: (c5)
First open the valve plug (1). insert the plastic adapter in the large
opening of the dual head (2). to lock in place, please fold down the
lever at the pump head (3). now insert the adapter into the object to
be inflated (4).
inflating balls: (c6)
insert the metal adapter in the large opening of the dual head (1). to
lock in place, please fold down the lever at the pump head (2). now
insert the adapter into the ball (3).
assembly options of the bag on the bicycle: (d)
to transport the pump on the bicycle, you can attach the bag to the
bicycle using the three velcro fasteners as shown in the figure
(d).
!
cleaning & care instructions:
- clean with a damp cloth
- do not immerse in water
- regularly inspect the pump’s screw joints for secure attachment
before use
- lubricate the pump seal with acid-free grease at least once a year
to do this, unscrew the nut on the pump cylinder, after which you
can remove the pump plunger with the spring and grease the seal
ring. assembly is carried out in reverse order.
(e1/e2)
- store Mini Foot air Pump in a cool, dry place protected from uv light.
disposal:
the packaging is made of 100% environmentally-friendly materials
which you can dispose of via your local recycling points. Please ob-
tain information about the disposal options from your community or
municipal government.
Warranty:
Warranty of the Monz handelsgesellschaft international MBh & co. kg.
dear customer, this device comes with a three-year warranty, valid
from the date of purchase. in case of defects of this product, you will
have legal rights towards the seller of this product. these legal rights
shall not be limited by our warranty as set out below.
Warranty terms:
the warranty term starts on the date of purchase. Please keep the original
receipt in a safe place. this document is required as proof of purchase.
