Operation of the dual head and adapters:
e.g. balls
e.g. air mattresses
e.g. infl atable boats
Infl ating bicycle tyres with a Schrader valve:
First remove the dust protection cap (1). Insert the dual head with the large opening into the
valve (2). To lock in place, please fold up the lever of the dual head (3).
Infl ating bicycle tyres with a Dunlop valve:
First remove the dust protection cap (1). Insert the dual head with the small opening into the
valve (2). To lock in place, please fold up the lever of the dual head (3).
Infl ating bicycle tyres with a Presta valve:
First remove the dust protection cap (1). Detach the valve nut (2a-2c). Insert the dual head
with the small opening into the valve (3). To lock in place, please fold up the lever of the dual
head (4).
Infl ating air mattresses, infl atable boats, infl atable toys, etc.:
First open the valve plug (1). Select the appropriate plastic adapter and insert it into the large
opening of the dual head (2). To lock in place, please fold up the lever of the dual head (3).
Now insert the adapter into the object to be infl ated (4).
Infl ating balls:
Insert the metal adapter in the large opening of the dual head (1). To lock in place, please fold
up the lever of the dual head (2). Now insert the adapter into the ball (3).
For infl ating bicycle tyres with a Schrader valve, e.g.
on automobiles, handcarts and trailers.
For infl ating bicycle tyres with a Dunlop valve, e.g. on
city/trekking bikes.
For infl ating bicycle tyres with a Presta valve, e.g. on
racing bicycles and mountain bikes.
(Valves not included)
To lock in place, please
fold up the lever of the
dual head.
1
2
3
1
2
3
dual head
1
2
3
1
2
4
3
1
4
3
2a
2b
2c
4
5
