8 GB
Anti-Scratch
The built-in visor features a
special coating to minimise
scratches . This coating prevents
rapid scratching of the external
part of the visor .
Construction for those who
wear glasses
The helmet is also suitable for those who wear
glasses . An extra soft padding improves the
wearing comfort for those who wear glasses .
HCM Technology
High Density Copolymer
Matrix: High quality ABS
plastic is formed under extreme heat and
pressure to make a robust and impact-resistant
outer shell .
A.I.R. ventilation system
Newly developed A .I .R .
ventilation system – with the
ventilation flaps opened, nega-
tive pressure draws out warm air .
Use and Installation
Instructions
Inner Lining
The inner lining (9) can be completely removed
and cleaned separately (see care instructions).
To remove the inner lining loosen the neck guard
connected to the inner pad and pull the inner
pad clips out of the front of the helmet (see
Fig. A).
Snap-Fastener System
The snap-fastener enables an individual and
quick vernier adjustment of the chin strap .
Press the snap-fastener together until the helmet is
sitting comfortably but firm (see Fig. B).
By means of the snap at the end of the chinstrap,
the excess chinstrap can be attached to addition-
ally secure it .
Cheek Pads
The cheek pads (7) are affixed via three press-
studs respectively in the helmet . You can easily
remove the pads (see Fig. C).
When securing the cheek pads inside the helmet
you must hear every press stud click in .
Acoustic Damping
The acoustic damping (8) is for noise reduction,
in particular when driving at high speeds .
Press the acoustic damping into the cavity of
the cheek pads (see Fig. D). The acoustic side
pad equipped with Velcro faces towards the
helmet shell .
Top Vent
The top vent (1) can be opened and closed by
means of a slider (see Fig. E).
A.I.R. ventilation system
Open and close the A.I.R. ventilation system (2)
with a slide (see Fig. F).
Visor Replacement
Removing the visor
Turn the outer covers counter-clockwise to release
(see Fig. G). Remove the visor, being careful not
to lose the control elements . The control elements
are marked L and R .
Installing the visor
Place the visor onto the inner control element,
then press the outer control element into the
designated holder . The arrow on the control ele-
ment should point up . Be sure to place the control
element marked “L” at the left of the helmet (see
Fig. H).
Lastly, insert the cover into the opening and se-
cure by turning a quarter clockwise turn . Be sure
the logo is correctly positioned (see Fig. I).
