be connected with or without the
connection cable (see fig. D).
Mounting the distance
sensor (see fig. E or F)
Note: You will need an electric drill
for installation.
CAUTION! RISK OF INJURY!
Refer to the operating instructions for
your electric drill.
Note: When installing the sensor,
make sure the side with the two small
diodes is facing a surface (e.g. the
inner side of a cabinet door) that is
not more than approx. 5 cm away.
Note: If the inner side of cabinet
has a dark surface (e.g. black color),
the distance between the sensor and
inner side of cabinet door should not
be more than approx. 2 cm.
CAUTION! Ensure that you do
not damage any cables in the
wall.
