13 GB/IE
Avoid bending the product.
Otherwise the insulation could
be damaged.
Installation
The LED strip light can be connected
using a connection cable (Fig. B) or
without a connection cable (Fig. C).
Mounting the product
on a cupboard
Note: Thoroughly clean the surface
on to which you intend to install the
product. The surface must be clean,
dry and free of grease. Otherwise
the self-adhesive foil may not stick
properly.
1. Using a pencil, mark the position
on the wall on to which you
intend to attach the LED light
strip. If necessary, use a spirit
level as a guide.
2. Pull the paper from the self-
adhesive foil on the back of the
LED light strip.
3. Position the self-adhesive foil on
the markings and press to fix it
firmly into place (Fig. D).
4. Connect the LED light strip to the
power lead or connect the LED
light strip to the connection lead
to connect it to an additional
light (Fig. F).
