Before installation / Installation / Preparing the product for use
- Pencil / Marking tool
- Voltage tester
- Screwdriver
- Electric drill
- Drill
- Edge cutter
- Ladder
 Before installation
Important: The electrical connection must be
carried out by a qualified electrician or someone
trained to perform electrical installations. This person
must be familiar with the features of the light and
the connection requirements.
  Familiarise yourself with all instructions and
diagrams in this manual as well as with the
light before installation.
  Before installation, ensure that the cable that
the light is to be attached to is not live. Remove
its fuse or switch off the automatic cutout in the
fuse box (0 position).
  Use the voltage tester to check that there is no
voltage.
 Installation
 Fitting the light
  Remove the screws 2 visible on the side of the
terminal housing 6 and take the installation
frame 1 on the back off (see diagram).
  Mark the boreholes using the slotted holes pro-
vided for the screws in the installation frame
1 .
  Now drill the screw holes (approx. 6 mm, depth
approx. 40 mm). Ensure that the feed cable is
not damaged.
  Insert the dowels into the drilled holes. Fasten
the mounting bracket
1 in place with the
supplied screws.
  Connect the light’s connection cable to the
mains connection cable
3 using the insulating
screw joint 4 (see diagram).
  Ensure that the cables have been connected in
line with the correct colour coding.
  Now connect the earthed conductor (green-
yellow) to the earth terminal labelled in the
terminal housing
6 (see diagram).
  Screw the light onto the installation frame 1
using the screws 2 .
  Place the lamp glass 11 carefully over the
fitting 10 and fasten it in place by tightening the
threaded ring 12 using the supplied tool 13 .
  Use a clean, fluff-free cloth when you are
replacing a bulb
14 .
  Rotate the bulb 14 carefully clockwise into
the fitting.
Check that the bulb is correctly seated.
Your light is now ready for operation.
 Directing the light
  Never change the direction of the light while it
is switched on.
  Rotate the articulated arm 9 into the desired
position.
 Preparing the product for use
 Inserting / replacing batteries
  Release the screw from the battery compartment
of the remote control handset
8 (rear side) by
unscrewing it with a Phillips screwdriver in the
direction.
  Remove the used battery, if present.
  Insert a new battery into the battery compartment.
Use batteries type 23 A, 12 V only.
Note: Make sure you fit the battery the right
way round (polarity). The correct polarity is
shown inside the battery compartment.
  Close the battery compartment of the remote
control handset
8 (rear side) by screwing the
screw in with a Phillips screwdriver in the
direction.
