Silvercrest SMZS 260 E3 - Handbuch (Seite 9)

7 GB
Shredding
• Figure C: In order to work at normal
speed, press the motor block3 down
and then release it again.
• Figure D: In order to work at high
speed, additionally press down on the
TURBO1 button.
• Work using short pulses (1pulse: press
for approx. 1second). The number and
length of the pulses will depend on the
quantity and consistency of the food. See
the specifications given in the "Process-
ing table" section.
• Repeatedly check the result. If the food
is not being chopped evenly:
- Pull out the mains plug2, remove the
motor block3 and thoroughly shake
the vessel7.
- If food is sticking to the inside wall of
the vessel, rotate the working cover4
anti-clockwise and remove it. Push the
pieces downwards using a spatula.
- Put all the pieces back together be-
fore you reinsert the mains plug2 into
a wall socket and resume work.
6.2 Cream attachment
Application area
The cream attachment5 has been specially
designed for whipping cream in the multi
chopper. It is placed on top of the blade in-
sert6. There are two options here: one for
smaller quantities (up to 100 ml) and one for
larger quantities (100 to 200 ml).
NOTE: Wherever possible, work with well
cooled whipping cream (refrigerator temper-
ature), so that the whipped cream reaches a
firm consistency.
Whipping cream
1. Place the vessel7 on the vessel cover9.
2. Carefully place the cream attachment5
onto the blade insert6 from above.
- Up to 100 ml: Figure E: Rotate the
cream attachment so that it is in con-
tact with both blades and clicks into
place.
- 100 to 200 ml: Figure F: Rotate the
cream attachment so that it is in con-
tact with one of the blades and clicks
into place. This causes it to sit higher
in the vessel.
3. Place the blade insert6 together with
the cream attachment5 onto the spin-
dle8 in the vessel.
4. Pour the cooled whipping cream (maxi-
mum 200 ml) into the vessel7.
5. Place the working cover4 onto the ves-
sel7 in such a way that the two small
tabs on the working cover fit into the
grooves in the vessel and rotate the
working cover clockwise until it clicks
into place.
6. Place the motor block3 into the upper
edge of the working cover4.
NOTE: The motor block does not fit
onto the working cover entirely straight
on the right-hand side.
7. Press down on the motor block3 and hold
it pressed down for approx. 30 to 50 sec-
onds. Check the result while doing so.
6.3 Remove food
NOTE: You can choose to use the vessel cov-
er9 as the cover or the base (FigureG).
1. Disconnect the mains plug2 from the
wall socket.
2. Remove the motor block3.
3. Rotate the working cover4 anti-clock-
wise and remove it.
4. Carefully remove the blade insert6 (if
necessary together with the cream at-
tachment5) from the vessel7.
5. Remove the food, e.g. using a spatula.
6. Clean the device as soon as possible af-
ter use.
