- 16 -
4. In the display the year "2011" blinks. With the  or

button t you can change the year and confirm with
the OK button l. With the  or  button t you can
change the now blinking month and confirm with the OK
button l. Now the day indicator blinks which you can
also change with the  or  button t.
5. To save press the OK button l. The "DATE SETUP"
notice appears again.
Adjust contrast
You can set the display's contrast as follows:
1. Hold down the S button r for a little longer than 3 sec-
onds. The notice "LANGUAGE SETUP" appears.
2. With the  or  button t select "SYSTEM SETUP" and
confirm with the OK button l.
3. With the  or  button t select "CONTRAST SETUP"
and confirm with the OK button l.
4. In the LCD display q the contrast value now blinks which
you can set with the  or  button t.
Display readout:
0 = highest contrast:
15 = lowest contrast
5. With the OK button l you can save the desired setting.
The notice "CONTRAST SETUP" appears again.
Background Illumination
You can set how long the LCD display’s q background and
the button illuminations remain alight after completion of the
operation.. Thereby taking into account that the longer the il-
lumination remains lit the shorter the battery life will be.
1. Hold down the S button r for a little longer than 3 sec-
onds. The notice "LANGUAGE SETUP" appears.
2. With the  or  button t select "SYSTEM SETUP" and
confirm with the OK button l.
3. With the  or  button t select "BACKLIT SETUP" and
confirm with the OK button l.
4. In the LCD display q now blinks the second count for the
length of time that the light is to be left on which you can
set with the   buttons t from 0 to 60. If you select
"0" the background illumination will shut off completely.
5. With the OK button l you can save the desired setting.
The notice "BACKLIT SETUP" appears again.
Setting the global volume/mute switching
So that you don’t always have to first press a device button for
the volume control and mute switching, for these functions the
URC always only responds to an individual device. You can
determine this target device yourself.
1. Hold the S button r down for a little longer than
3 seconds. The notice „LANGUAGE SETUP“ appears.
2. With the  or  button t select “SYSTEM SETUP” and
confirm with the OK button l.
