Notwendiges Werkzeug Tools required
(ill. 1)
Abisolierzange „Stripax“
Bestell-nr. 25.0015 (ill. 1)
Cable stripper “Stripax”
Order No. 25.0015
(ill. 2)
- Lötkolben 60W
- Lötdraht
z.B. bleifreies Lot Ø 1,5
#58/405 (SN95.8Ag3.5Cu.7)
ANSI/J-STD-004
Bezugsquelle:
www.kester-online.de (ill. 2)
- Soldering iron 60W
- Solder
e.g. lead free solder Ø 1,5
#58/405 (SN95.8Ag3.5Cu.7)
ANSI/J-STD-004
Source of supply:
www.kester-online.de
(ill. 3)
Hilfswerkzeug A-SAPP4-L.
Empfohlenes Material: Stahl (ill. 3)
Auxiliary tool A-SAPP4-L.
Recommended material: Steel.
(ill. 4)
Hilfswerkzeug B-SAPP4-L
Empfohlenes Material: Stahl (ill. 4)
Auxiliary tool B-SAPP4-L
Recommended material: Steel.
Notwendiges Werkzeug Tools required
(ill. 5)
Crimpzange PZK3
Bestell-Nr. 25.0018 (ill. 5)
Crimping pliers PZK3
Order-No. 25.0018
(ill. 6)
Hilfswerkzeug B-SL
Empfohlenes Material: Stahl (ill. 6)
Auxiliary tool B-SL
Recommended material: Steel
