13
Motor
Drive Belt / DC Servo-controlled Motor with optical speed control
Speed settings 33/45/78
Wow & Flutter < ±0,08 % (DIN WTD)
Tonearm
Function All functions can be fully automatic or manual
Bearing Ball-bearing
Effective length 221,5 mm
Offset Angle 25,6°
Overhang 19 mm
Type statically balanced with counterweight
Stylus Pressure Range 0 to 4 g
Cartridge Weight Range 5 g to 9 g
Factory installed Pick-up Ortofon 2M Red
Replacement Stylus Ortofon Stylus 2M Red
Platter
Material Aluminium Die-cast
Mat Rubber 2,5 mm
Bearing Hardened Steel Spindle, Brass Bushing
Diameter 305 mm
Weight incl. Mat 850 g
Plinth
Surface Finish Folded MDF Construction with a Black Vinyl Veneer
Feet Ø 62 mm / Elastomer Damping Element
Connection RCA socket
Connection to Phono Input YES
Connection to Line Input YES
Digital Output X
Dimension (closed dust cover) 435 x 367 x 145 mm
Dimension (open dust cover) D: 415 mm / H: 400 mm
Weight 6,2 kg
Power Supply
The efficiency readings were taken with an input Voltage
of 230 V AC at 50 Hz
Type FJ-SW1202000N
Input Voltage 100 (-10 %) V AC to 240 (+10 %) V AC
Frequency 50 / 60 Hz
Output Voltage 12 V DC
Output Current 2,0 A
Output Watt 24 W
Average Efficiency During Operation ≥ 86.2%
Power Consumption at Idle < 0,1 W
Technical Specifications
