Northern Connectors Binder RD24 Industrial Circular Connectors (693 Series) Benutzerhandbuch
Rd24 steckverbinder rd24 connectors
1
RD24
Kabelsteckverbinder
• Steckverbinder mit Schraubverriegelung
• Schutzart IP67
1)
• Varianten mit VDE-, SEV-, UL-Zulassung
• 3 Anschlusstechniken:
– LÖTanschluss
– SCHRAUBanschluss
– CRIMPanschluss für gedrehte Crimp-
kontakte (die u.a. auch in schweren
Rechtecksteckverbindern nach
DIN 43 652 eingesetzt werden)
Cable Connector
• Connector with screw locking
• Degree of protection IP67
1)
• Versions with VDE-, SEV-, UL-approval
• 3 termination possibilities:
– SOLDER termination
– SCREW termination
– CRIMP termination for turned crimp
contacts (which are used in heavy duty
rectangular connectors DIN 43652)
1)
Erläuterung der Schutzarten siehe Seite TI-3 – TI-4. /
1)
Explanation of protection standards see page TI-3 – TI-4.
RD24 Steckverbinder
RD24 connectors
