Leistungs Steckverbinder Serie 692 · 693
Power connectors series 692 · 693
Bestell-Nr.
Ordering-No.
Bezeichnung
Description
Abbildung
Figure
Maßzeichnung
Drawing
Polzahl
Contacts
3+PE
6+PE
6+PE
6+PE
Kabeldurchlass
Cable outlet
Kabeldose, PG13,5
Female cable connector, PG13,5
Crimpkontakte siehe Seite 33.
Crimp contacts see page 33.
Ш 29
~ 74
Ш
27
~ 78
3+PE
6+PE
6+PE
6+PE
Technische Daten
Specifications
Polzahl
Steckverbinder Verriegelung
Anschlussart
Anschlussquerschnitt
Kabeldurchlass
Schutzart
Mechanische Lebensdauer
Obere Grenztemperatur
Untere Grenztemperatur
Bemessungsspannung
Bemessungs-Stoßspannung
Verschmutzungsgrad
Überspannungskategorie
Isolierstoffgruppe
Bemessungsstrom (40°C)
Durchgangswiderstand
Material Kontakt
Kontaktoberfläche
Material Kontaktkörper
Material Gehäuse
Number of contacts
Connector locking system
Termination
Wire gauge
Cable outlet
Degree of protection
Mechanical operation
Upper temperature
Lower temperature
Rated voltage
Rated impulse voltage
Pollution degree
Overvoltage categorie
Material group
Rated current (40 °C)
Contact resistance
Material ot contact
Contact plating
Material of contact body
Material of housing
schrauben/screw
schrauben/screw
löten/solder
schrauben/screw
crimpen/crimp
0,5–2,5 mm
2
(AWG 20–14)
max. 0,75 mm
2
(max. AWG 18)
0,34–1,5 mm
2
(AWG 22–16)
0,14–1,5 mm
2
(AWG 26–16)
10–12 mm
IP67
> 500 Steckzyklen/> 500 mating cycles
+ 100 °C
– 40 °C
400 V (600 V UL)
250 V
6000 V
4000 V
3
III
llI
16 A (12 A UL)
10 A (8 A UL)
≤ 5 mΩ
CuSn (Bronze/bronze), CuZn (Messing/brass)
Ag (Silber/silver)
PBT (UL 94 V-0)
PBT (UL 94 V-0)
10–12 mm
10–12 mm
10–12 mm
10–12 mm
Kabeldose, PG13,5
Female cable connector, PG13,5
Crimpkontakte siehe Seite 33.
Crimp contacts see page 33.
Ш 29
~ 74
Ш
27
~ 78
Anschlussart
Termination
schrauben
screw
löten
solder
schrauben
screw
crimpen
crimp
Bestell-Nr.
Ordering-No.
99 0210 15 04
99 0214 15 07
99 0218 15 07
99 0202 15 07
Polzahl
Contacts
3+PE
6+PE
6+PE
6+PE
Kabeldurchlass
Cable outlet
10–12 mm
10–12 mm
10–12 mm
10–12 mm
Anschlussart
Termination
schrauben
screw
löten
solder
schrauben
screw
crimpen
crimp
Bestell-Nr.
Ordering-No.
99 4222 14 04
99 4226 14 07
99 4218 14 07
99 4202 14 07
