Rd24, 19 rd24 – Northern Connectors Binder RD24 Industrial Circular Connectors (693 Series) Benutzerhandbuch
Seite 19
19
RD24
RD24
BF
-A
BF
-C
M18
7/
8‘
‘
M12
-U
S
VL
M8
M12
-A
M5
M12
-S
BF
-B
M1
2-T
M12
-D
M12
-B
Ver
tei
ler
RD3
0
M25
RD
24
Bajo
ne
tt
M23
M1
6 I
P67
M9
IP
67
PP
IP
67
M1
6 I
P4
0
M9
IP
40
MP
P I
P67
Bajo
ne
tt
SI I
P67
SI I
P4
0
Bajo
ne
tt
NCC
PP
IP
67
SI I
P67
Leistungs Steckverbinder Serie 692 · 693
Power connectors series 692 · 693
Bestell-Nr.
Ordering-No.
Bezeichnung
Description
Abbildung
Figure
Maßzeichnung
Drawing
Polzahl
Contacts
3+PE
4 x 1,5 PVC
6+PE
7 x 0,75 PVC
3+PE
4 x 1,5 PVC
6+PE
7 x 0,75 PVC
Kabelstecker
Male cable connector
Technische Kabeldaten siehe Seite 21.
Specifications of cable see page 21.
L
Ш 29
Ш
8
54
Ш 23
3+PE 6+PE
Technische Daten
Specifications
Polzahl
Steckverbinder Verriegelung
Anschlussart
Anschlussquerschnitt
Kabeldurchlass
Schutzart
Mechanische Lebensdauer
Obere Grenztemperatur
Untere Grenztemperatur
Bemessungsspannung
Bemessungs-Stoßspannung
Verschmutzungsgrad
Überspannungskategorie
Isolierstoffgruppe
Bemessungsstrom (40°C)
Durchgangswiderstand
Material Kontakt
Kontaktoberfläche
Material Kontaktkörper
Material Gehäuse
Number of contacts
Connector locking system
Termination
Wire gauge
Cable outlet
Degree of protection
Mechanical operation
Upper temperature
Lower temperature
Rated voltage
Rated impulse voltage
Pollution degree
Overvoltage categorie
Material group
Rated current (40 °C)
Contact resistance
Material ot contact
Contact plating
Material of contact body
Material of housing
schrauben/screw
crimpen, am Kabel angespritzt/crimp, moulded
1,5 mm
2
(AWG 16)
0,75 mm
2
(AWG 18)
—
IP67
> 500 Steckzyklen/> 500 mating cycles
+ 80 °C
– 25 °C
400 V
250 V
6000 V
4000 V
3
III
llI
16 A
8 A
≤ 5 mΩ
CuZn (Messing/brass)
Ag (Silber/silver)
PA 12
PUR
Winkelstecker
Male angled connector
Technische Kabeldaten siehe Seite 21.
Specifications of cable see page 21.
L
Ш
21
Ш 29
35°
Ш 8,
6
53
48,
8
1
2
3
Bestell-Nr.
Ordering-No.
79 0231 20 04
79 0235 20 07
Polzahl
Contacts
Bestell-Nr.
Ordering-No.
79 0233 20 04
79 0237 20 07
Kabellänge
Cable length
2 m
Kabellänge
Cable length
2 m
