Leistungs Steckverbinder Serie 692 · 693
Power connectors series 692 · 693
Bestell-Nr.
Ordering-No.
Bezeichnung
Description
Abbildung
Figure
Maßzeichnung
Drawing
Polzahl
Contacts
3+PE
6+PE
6+PE
6+PE
Kabeldurchlass
Cable outlet
Winkelstecker, PG9
Male angled connector, PG9
Crimpkontakte siehe Seite 33.
Crimp contacts see page 33.
Ш 29
60
24
Ш 20
~ 32
36
3+PE
6+PE
6+PE
6+PE
Technische Daten
Specifications
Polzahl
Steckverbinder Verriegelung
Anschlussart
Anschlussquerschnitt
Kabeldurchlass
Schutzart
Mechanische Lebensdauer
Obere Grenztemperatur
Untere Grenztemperatur
Bemessungsspannung
Bemessungs-Stoßspannung
Verschmutzungsgrad
Überspannungskategorie
Isolierstoffgruppe
Bemessungsstrom (40°C)
Durchgangswiderstand
Material Kontakt
Kontaktoberfläche
Material Kontaktkörper
Material Gehäuse
Number of contacts
Connector locking system
Termination
Wire gauge
Cable outlet
Degree of protection
Mechanical operation
Upper temperature
Lower temperature
Rated voltage
Rated impulse voltage
Pollution degree
Overvoltage categorie
Material group
Rated current (40 °C)
Contact resistance
Material ot contact
Contact plating
Material of contact body
Material of housing
schrauben/screw
schrauben/screw
löten/solder
schrauben/screw
crimpen/crimp
0,5–2,5 mm
2
(AWG 20–14)
max. 0,75 mm
2
(max. AWG 18)
0,34–1,5 mm
2
(AWG 22–16)
0,14–1,5 mm
2
(AWG 26–16)
6–8 mm
IP67
1)
> 500 Steckzyklen/> 500 mating cycles
+ 100 °C
– 40 °C
400 V (600 V UL)
250 V
6000 V
4000 V
3
III
llI
16 A (12 A UL)
10 A (8 A UL)
≤ 5 mΩ
CuZn (Messing/brass)
Ag (Silber/silver)
PBT (UL 94 V-0)
PBT (UL 94 V-0)
6–8 mm
6–8 mm
6–8 mm
6–8 mm
Winkelstecker, PG9
Male angled connector, PG9
Crimpkontakte siehe Seite 33.
Crimp contacts see page 33.
Anschlussart
Termination
schrauben
screw
löten
solder
schrauben
screw
crimpen
crimp
Bestell-Nr.
Ordering-No.
99 0209 70 04
99 0213 70 07
99 0217 70 07
99 0201 70 07
Polzahl
Contacts
3+PE
6+PE
6+PE
6+PE
Kabeldurchlass
Cable outlet
6–8 mm
6–8 mm
6–8 mm
6–8 mm
Anschlussart
Termination
schrauben
screw
löten
solder
schrauben
screw
crimpen
crimp
Bestell-Nr.
Ordering-No.
99 4221 70 04
99 4225 70 07
99 4217 70 07
99 4201 70 07
1)
IP65 bei Leitungs-Ø 6–7 mm. /
1)
IP65 for cable-Ø 6–7 mm.
