Abbreviations
and Descriptions
Used
Warning notices
affixed to the de-
vice The Fronius String Control 100/12 contains warning notices and safety symbols. These
warning notices and safety symbols must NOT be removed or painted over. The notices
and symbols warn against operating the equipment incorrectly, as this may result in seri-
ous injury and damage.
Safety Symbols:
DC cable 'OUT' DC output cable from Fronius String Control 100/12 to inverter;
the polarity of the DC cable ‘OUT’ depends on how the solar
module strings are connected to the Fronius String Control 100/
12.
DC cable 'IN' Solar module strings from the solar modules to the Fronius
String Control 100/12;
one solar module consists of one DC+ cable and one DC- cable.
Danger of serious injury or damage due to incorrect operation
Do not use the functions described until you have thoroughly read and under-
stood the following documents:
-
These operating instructions
- all operating instructions for system components of the photovoltaic sys-
tem, especially the safety rules
Dangerous electrical voltages
