JB-Lighting Varyscan P3 250 HTI - Handbuch (Seite 26)

3.5 Lamp control and lamp ignition
There are differnt modes for lamp ignition and lamp control available:
Lamp ignition configuration is set in the fixtures personality configuration in menu
LAMP MODE
possibility no.1: The lamp ignites as soon as the fixture powers up (AUTO START)
possibility no 2: The lamp ignites as soon as the fixture powers up and a DMX value
between 248-255 is send on channel no. 5 (AUTO OFF).
possibility no 3: The lamp ignites so soon as the fixture powers up and any DMX signal
is connected to the fixture . (AUTO DMX)
Configuration of lamp control:
The lamp control configuration is independent to the lamp ignition mode.
The lamp control is based on DMX values. It is used to switch off the lamp by
means of the control console.
To enable the lamp control mode enter personality configuration of the fixture.
Activate menu LAMP ON/OFF DMX
If the option is selected in menu, the lamp can only
be controlled by DMX if possibility no. 2 is selected.
OFF LAMP ON/OFF DMX
(switched off)
If the option is selected in the lamp will ignite like
discribed before and it can always be controlled (switched off) by DMX if there is a
DMX value send between 232-239 on channel no. 5 for more than 3 seconds.
ON LAMP ON/OFF DMX menu,
Activate the standalone mode:
The standalone mode is activated in the menu: DMX/STANDALONE
independent if it was programmed manually or by a connected DMX board.
To enter menu DMX/STANDALONE press key "Menu" and afterwards key "+"
three times. You will find D
To confirm press "Enter".
Select standalone-function by pressing key "+" and press "Enter" one time
to activate.
will be shown on the display
MX/STANDALONE displayed.
S-ALONE: 1 / 2
Deactivate the standalone mode:
To deactivate standalone mode press "Enter" and key "-" one time.
The display will show:
Press key "Enter" again and find
displayed
Escape by pressing key "Menu"
DMX MODE
DMX/STANDALONE
27
