3.5 Lamp control and lamp ignition
There are differnt modes for lamp ignition and lamp control available.:
Lamp ignition configuration is set in the fixtures personality configuration in Menu
possibility no.1: The lamp ignites as soon as the fixture powers up
possibility no 2: The lamp ignites as soon as the fixture powers up and a DMX value
between 248 - 255 is send on channel no. 5
possibility no 3: The lamp ignites so soon as the fixture powers up and any DMX signal is
connected to the fixture.
The lamp control configuration is independent to the lamp ignition mode.
The lamp control is based on DMX values. It is used to switch off the lamp by means of the
control console.
To enable the lamp control mode enter personality configuration of the fixture.
Activate menu
If the option is selected in menu, the lamp can only be controlled
(switched off) by DMX if possibility no. 2 is selected.
If the option is selected in the lamp will ignite like discribed
before and it can always be controlled (switched off) by DMX if there is a DMX value send
between 232-239 on channel no. 5 for more than 3 seconds.
LAMP
MODE
(AUTO START)
(AUTO OFF)
(AUTO DMX)
LAMP ON/OFF DMX
LAMP ON/OFF DMX
LAMP ON/OFF DMX menu,
Configuration of lamp control:
OFF
ON
Activate the standalone mode:
The standalone mode is activated in the menu: DMX/STANDALONE
independent if it was programmed manually or by a connected DMX board.
To enter menu DMX/STANDALONE press key MENU and afterwards key + three times.
You will find D
To confirm press Enter.
Select standalone-function by pressing key + and press ENTER one time to activate.
will be shown on the display
MX/STANDALONE displayed.
S-ALONE: 1 / 2
Deactivate the standalone mode:
To deactivate standalone mode press ENTER and key - one time.
The display will show:
Press key ENTER again and find
displayed
Leave menu by pressing key MENU
DMX MODE
DMX/STANDALONE.
