Stückliste Varyscan 6 Display
Stückliste Varyscan 6 Display --PPlatine
latine
C1
820P
C2
820P
C3
820P
C4
820P
C5
820P
C6
820P
C7
3N3
C8
3N3
C9
100N
C10
100N
C11
100N
C12
100N
C15
100N
C16
100N
C18
100N
C19
100N
C20
100N
C21
100N
C22
100N
C23
100N
C24
100N
C25
100N
C26
100N
C28
47U/25
C29
10U/16
C30
220U/35
C31
220U/35
C32
2200/40
C33
4700U/25
C34
470U/16
C35
3N3
C36
820P
C37
820P
D1
LM336LP
D4
SA5_0CARL
D11
1N4003
D12
FBU4B
D13
FBU4B
F1
FUSE 4A T
F2
FUSE 6,3 A T
IC1
68HC11F1
IC2
27C256
IC3
ADM709LAN
IC4
AM26LS31
IC5
PBM3960
IC6
PBM3960
IC7
PBL3771
IC8
PBL3771
IC9
LS7266R1
IC10
PAL16L8
IC11
ADM483E
IC12
LM317T
IC13
PBL3771
JP1
AMP2
JP2
AMP2
JP3
AMP1
JP4
AMP1
JP5
AMP1
JP6
AMP1
JP7
AMPQuick2
JP8
AMPQuick12
JP9
AMPQuick12
JP10
AMPQuick4
LCD1
LCD1601_B
R1
1K
R2
8R2
R3
Nicht bestückt
R4
0R
R5
10K
R6
4K7
R7
10K
R8
9*10K SIP
R9
15K
R10
15K
R11
1K
R12
1K
R13
1K
R14
1K
R15
1R
R16
1R
R17
1R
R18
1R
R19
470R
R20
36R
R24
1K
R31
787R
R32
243R
R33
15K
R34
1R
R35
1R
R36
1K
R37
1K
S1
TASTSK_B
S2
TASTSK_B
S3
TASTSK_B
S4
TASTSK_B
Y1
YO16M
