25
JB-lighting Lichtanlagentechnik GmbH Sallersteigweg 15 D-89134 Blaustein Telefon +49 (0)7304-9617-0
3.2 Set to factory default
3.4 Standalone mode
3.3 DMX Addressing
Enter DMX address by means of the keys + and -. Confirm an store by pressing key ENTER
To set back the VS P6 to factory setting press key MENU one time.
will be displayed. Press key ENTER to enter FACTIRY DEFAULT menu.
Select and press key ENTER. will be displayed. Confirm by pressing
key ENTER again. The personal setting of the VS P6 will be set back to factory default.
FACTORY DEFAULT
LOAD DEFAULTS SURE
A sequence consisting of preprogrammed cues can be recalled by means of the Standalone
mode. The sequence will run as a loop.
Cues can be entered in two different ways.
The first way is to program every feature by means of the key of the units own control panel.
The second way is to program the cues by means of a connected DMX control console and to
store them on-board of the VS P6
Enter DMX values by means of the control panels keys:
Recall standalone mode:
Press key MENU first. The press key + five times (see page 24)
STANDALONE STEPS will be displayed. Confirm by pressing key ENTER
STEP NR. 1/1, will be shown. Confirm again by pressing ENTER
After this second confirmation the display will show: MODIFY 1/1
Now recall Modify Menü by pressing key ENTER.
The Modify menu enables access to all parameters of the unit. Use key + and - to recall the
desired parameter. Confirm choice by pressing ENTER. Enter DMX values by means of the
keys + and -.
Store DMX values by pressing key ENTER.
To escape press key MENU.
Add one step to the sequence:
Press key + untill MENU
is shown. INSERT
Confirm by pressing key ENTER.
SURE? will be displayed. Confirm by pressing key ENTER again.
A new step will be added to the sequence.
The DMX values of the last step will be automatically copied to the new step.
To alter DMX values enter Modify menu and proceed like describe in chapter:
Enter DMX values by means of the control panels keys
Delete one step of a sequence:
Recall the Standalone menu.
STANDALONE STEPS must be shown on the display.
Confirm by pressing key ENTER.
STEP NR: 1 / X will be displayed.
Use keys + and - to recall the desired step. Confirm selection by pressing key ENTER.
Select menu DELETE by pressing key +.
Confirm the selection of the step by pressing key ENTER.
SURE? will be displayed. Now confirm again by pressing key ENTER and the selected
step will be deleted.
