7. Specifications
Type VKCD-12110F2812IR
Art. No. 208981
Series eneo Dome Fix
System day&night
Video standard CCIR/PAL
Sensor size 1/3”
Imager CCD, Sony Effio S (960H)
Horizontal resolution 700 TVL
Signal-to-noise ratio 55dB
Sensitivity (at 50% video signal) 0.1Lux (colour), 0.03Lux (B&W) at F1.2, 50 IRE
Automatic gain control (AGC) ON/OFF switchable
Automatic electronic shutter (ESC) 1/50 ~ 1/10,000sec.
Manual electronic shutter (MES) 1/50 ~ 1/10,000sec.
Low speed shutter yes, 2x-256x
Digital Noise Reduction (DNR) yes, 2D NR, 3D NR
Backlight compensation BLC, HLC
Wide Dynamic Range (WDR) D-WDR
White balance ATW, one push, Anti CR, user defined
Blemish compensation no
IR cut filter switchable
Day/Night switching auto
Privacy zones masking 15 areas, masking, X/Y start/end
Menu languages English
OSD function control 4:3/16:9 compression, Zoom (4:3 format only), BIB (Video A/B or Y/C)
Text display supplied
Activity detection yes
Motion detector 4 zones, ON/OFF switchable
Mirror function V flip, H flip, H/V flip
Digital zoom yes
Analysis functions activity detection
Lens type varifocal
Focal length 2.8mm - 12mm
Horizontal angle of view 81.2° - 22,6°
MOD (Minimum object distance) 1.5m
Aperture range (F) F1.4
Video outputs composite (CVBS), 1Vp-p (C)VBS, 75ohms, BNC
Alarm inputs no
