6
GB IE CY
Technical data
Pressure Washer ........ PHD 100 D2
Mains connection ............. 230 V~, 50 Hz
Power consumption ....................1450 W
Mains cable .....................................5 m
Weight (incl. all parts) ...................6,1 kg
Safety class ...................................... II
Degree of protection .........................IPX5
Inflow temperature t, max. ................40°C
Inflow pressure p, max. .... 0,8 MPa (8 bar)
Operating pressure p ........ 7 MPa (70 bar)
Max. permissible pressure p. ...................
.................................. 10 MPa (100 bar)
Pumping rate, water ................... 5 l/min
Max. pumping rate, water ........ 6,6 l/min
Acoustic pressure level
(L
pA
) ........... 80,5 dB (A); K
pA
=3,0 dB (A)
Sound power level (L
wA
)
measured ....92,9 dB (A); K
wA
=3,0 dB (A)
guaranteed ........................... 97 dB (A)
Vibration (a
h
) ....... 0,7 m/s 2 ; K=0,15 m/s 2
The operating conditions during measuring
and the procedures used for measuring in
accordance with EN 60335-2-79:2009.
Technical and optical changes can be car-
ried out in the course of further development
without notice. All dimensions, references
and information of this instruction manual are
therefore without guarantee. Legal claims,
which are made on the basis of the instruc-
tion manual, cannot thus be considered as
valid.
Notes on Safety
This Section is concerned with the basic
safety rules when working with the pres-
sure washer.
Explanation of symbols
Attention!
Before beginning work, familiarise
yourself thoroughly with all the op-
erating elements, particularly with
how they function and operate. Ask
a specialist if necessary.
Attention: Remove the plug from the
socket as soon as the power lead is
damaged or cut.
The pressure washer is not suitable
for direct connection to the drinking
water supply system.
CAUTION. pressure wash-
ers can be dangerous if
they are not operated cor-
rectly! The jet must never
be directed at people,
animals, electric equipment
connected to the power
supply or against the actual
pressure washer.
Information of the acoustic power
level L
WA
in dB.
Electric appliances should not be dis-
posed of in the domestic garbage.
Safety class II
Symbols in the manual
Warning symbols (the danger
can be explained at the place
of the exclamation mark)
with information on damage
and injury prevention.
