9
CY IE GB
• The cross-section of the power supply
cable must not be less than 2 x 2,5
mm².
• Wear sturdy footwear to protect
against electric shock.
Start-up
In keeping with current regulations
a pressure washer must never be
operated off the drinking water
mains supply without a controlla-
ble backflow preventer. A suitable
backflow preventer in conformity
with EN 12729 type BA must be
used.
Water that has passed through a backflow
preventer is classified as undrinkable.
A backflow preventer is available
from specialist retailers.
• Employ an ordinary garden hose for
the water intake and ensure sufficient
length.
Setting up
B
• Screw the equipment side of the
high-pressure hose connection
(2) to the high-pressure hose con-
nection (3) on the equipment.
• Screw the gun side of the high-
pressure hose connection (1) to
the spray gun (10)
• Establish the water supply by
connecting the rapid-action wa-
ter supply connector to the water
connection with sieve insert (8).
C • Connect to the spray gun (10)
by inserting and screwing in the
jet tube (11).
• If the jet pipe (11) is fitted, screw
in with the jet pipe (11) to con-
nect either the adjustable fan
nozzle (12) or the high pressure
nozzle (13).
Screw in to connect the deter-
gent container with nozzle (14)
directly to the spray gun (10).
With using the cleaning agent
container with the nozzle ( A
14), pour only cleaning agent
into the container. It is sucked in
automatically.
The width of the jet can be increased by
turning the end of the nozzle to the left. To
reduce the width of the jet, turn the end of
the nozzle to the right.
Mains connection
The pressure washer you have acquired is
already fitted with a mains plug. The pres-
sure washer must only be connected to an
earthed socket 230 V ~ 50Hz.
Only operate the pressure washer
after all the above points have been
observed.
• Ensure that the pressure washer is
turned off by its ON / OFF switch ( A
5).
• Insert the mains plug into the mains
socket
Operation
• Connect the equipment to the water
tap. Observe the regulations for the
use of a system separator.
• Turn on the water tap entirely.
