10
• Place the nozzle of the gas canister at the refill valve (6) of the gas soldering gun and
press it .
• Draw the nozzle of the gas canister out of the refill valve of the system as soon as the gas
begins to overflow out. OVERFILLING THE TANK WILL CAUSE THE FLAME TO
SPIT.
• Wait a few minutes before igniting the torch to allow the gas to stabilise.
CAUTION: Accessible parts may become very hot.
Keep small children away from the device.
Assembly of attachments(Figure B)
One hot air attachment (1), one torch attachment (2), four soldering tips (11-14) and one hot
air deflector are included in the contents, To fit the various attachments
proceed as described on the following pages.
5. Operation / use
CAUTION! Danger of burns! Allow the gas soldering iron
to cool completely before changing the attachments.
Use as soldering gun (Figure C)
The gas soldering gun is provided with the blow torch attachment, hot air/soldering
attachment and with a soldering tip can can be used as soldering gun.
• 4 soldering tips are included in the contents
• Choose the most suitable tip for your application and screw this firmly into the threaded
hole in the hot air / soldering attachment.. The pre-assembled soldering tip should be
removed beforehand as required.
