Florabest FBM 575 A1 - Handbuch (Seite 15)

ENGLISH -
ADJUSTMENT OF CLUTCH CABLE
Important:If, when you press the clutch lever, the automatic advance gear does not engage, the
clutch cable should be adjusted. To make fine adjustments, turn the adjuster wheel(Fig.I) counter
clockwise to engage advance gear earlier. To make rough adjustments, insert the spring (Fig.I) in
one of the subsequent holes in the lever.
5
MAINTENANCE
The user must only carry out the
maintenance and service work described
in this Operator's Manual. More extensive
work must be carried out by an
authorized service workshop.
General Inspection

Check that all screws and nut are tightened.
 Frequently check the mower and ensure that
all grass deposits are removed from beneath
the deck.
 Let your authorized service partner regu-
larly check the machine and make essential
adjustments and repairs.
 Always use genuine accessories.
Cutting Equipment

Check the cutting attachment for damage or
cracks. A damaged cutting attachment should
always be replaced. See section K.
 Always ensure the cutter is well ground and
balanced correctly.
Replacing or sharpening the blades should be
conducted by an authorized service workshop. Let
the service centre assess whether the blade can
be sharpened or must be replaced. The blades
should be balanced after sharpening.
Oil level
The lawn mower should stand on flat ground when
you check the oil level. Check the oil level with the
dipstick on the oil fller cap.
- Remove the oil cap and wipe the dipstick clean.
- Put the dipstick back in. The oil filler cap must
be completely screwed down to give a correct
picture of the oil level.
Caution! Switch off the motor and disconnect
the spark plug before undertaking any mainte-
nance work.
- If the oil level is low, fill engine oil up to the upper
level on the dipstick.
For further explanation of oil change and engine
maintenance, see Engine Maintenance Manual.
Cleaning
Never clean the mower by pouring water over it:
this may seriously damage the electric system.
Use a brush to clean the top from leaves, dust
and grass.
If the machine needs to be tilted, it should only be
with exhaust muffler facing downwards and with
as little fuel in the tank as possible.
Caution: Make sure engine is cold as fuel
could leak through the ventilation in the
cap while tilting machine.
Cleaning under the bodywork. With machine at a
standstill and turned off:
- Attach fitting (14) on the deck to the water supply
tap. Turn on the tap.
- start up the motor (blade in rotation), allowing it
to warm up for a few minutes.
- at the end of cleaning switch off the engine,
turn off the tap, detach the tube from the deck
connection.
