United Office ULGD 350 A1 - Handbuch (Seite 14)

12 ULGD 350 A1
GB
IE
Appendix
Technical data
Operational voltage 220 - 240 V ∼, 50 Hz
Current consumption 1.6 A
Power consumption 350 W
Protection class
II/
Pouch width max. 230 mm
Pouch thickness for hot lamination max. 125 Micron
Pouch thickness for cold lamination max. 200 Micron
Lamination times
Sheet size
Pouch thickness switch
position: 80 Micron
Pouch thickness switch
position: 125 Micron
DIN A4 approx. 40 s approx. 51 s
DIN A5 approx. 29 s approx. 36 s
Overheating protection
This appliance is fi tted with an overheating protector. If the motor overheats
due to overloading, the appliance switches itself off automatically. In this case,
disconnect the power cable and wait until the appliance has cooled down to
room temperature. You can then reconnect the power cable with a mains power
socket and take the appliance back into operation. We recommend that you let
the appliance cool down for about 30 minutes after 2 hours of operation.
Notes on the Declaration of Conformity
This appliance complies, in regards to conformance with
the basic requirements and other relevent regulations, with
the EMC Directive 2004/108/EC, as well as the Directive
for Low Voltage Devices 2006/95/EC.
The complete original Declaration of Conformity can be
obtained from the importer.
