6 STGG 1800 A1
GB
IE
CY
Assembly and setting up
WARNING! RISK OF FIRE!
► Never place the appliance underneath wall
cupboards or next to curtains, cupboard
walls or other fl ammable objects.
► Set up the appliance at least 70 cm from any
fl ammable materials (e.g. curtains).
► Always place the appliance on a heat-resistant
surface.
► Set up the appliance with its rear side directly
against the wall. When doing so, ensure that
the wall is made of heat-resistant material
and that the lid 3 can open fully.
1) Remove all of the parts from the box and
remove the packaging material and any
protective fi lm.
2) Clean all components as described in Chapter
“Cleaning and care”. Ensure that all parts are
completely dry.
3) Place the appliance on a heat-resistant, clean
and level surface.
4) Place the drip tray 6 in the frame 5 so that
it sits in the recess to the left of the centre.
ATTENTION! DAMAGE TO PROPERTY!
► Never use the appliance without the drip
tray 6! Otherwise hot fat and other hot
liquids will drip down from the appliance
onto the surface below.
5) Place the griddle 1 onto the frame 5.
Ensure that the socket 2 is on the right side.
The griddle 1 must sit correctly in the frame
otherwise the thermostat 9 cannot be con-
nected to the socket 2.
6) Push the hinges of the lid 3 into the recess on
the frame 5 and close the lid 3.
7) Connect the thermostat 9 with the socket 2
on the appliance. Ensure that the thermostat
9 is pushed up to the stop in the socket 2.
Otherwise the appliance cannot heat up!
Before fi rst use
1) Open the lid 3 by pushing up the catch on
the handle 7 and, at the same time, pulling
the lid 3 upwards.
Open the lid 3 until the hinges slide down
into the hinge guides 4 and the lid 3 is fi rmly
in place.
2) Wipe the griddle 1 with a moist cloth.
3) Lightly grease the griddle 1 with fat or oil that
is suitable for baking/grilling. This allows any
cooking residues on the griddle 1 to be more
easily removed.
4) Close the lid 3 by lifting it lightly into the
hinge guide 4 so that it can be folded shut.
5) Insert the plug in a mains power socket and set
the temperature control 8 to level 5. The appli-
ance will heat up.
6) Wait for 10 minutes.
7) Then disconnect the plug and allow the appli-
ance to cool down.
NOTE
► The fi rst time the appliance heats up, a small
amount of smoke and smell may be generated
due to production-related residues. This is
completely normal and is not dangerous.
Provide suffi cient ventilation by opening a
window, for example.
8) Wipe the griddle 1 with a damp cloth after
cooling.
9) Clean the drip tray 6 as described in Chapter
“Cleaning and care”.
10) Ensure that all parts are completely dry before
operating the appliance.
The appliance is now ready for use.
