Powerfix PLS 10 A1
18 - English
These operating instructions have a fold-out cover. On the inside of the cover is a diagram of
the battery LED emitter with the components numbered. The meanings of the numbers are as
follows:
1 Handle
2 10 W Rechargeable Battery LED Working Light
3 Mounting
bracket
4 Knurled
screw
5 Stand
6 LED charging indicator
7 Rubber cover (for DC-IN receptacle)
8 DC-IN
receptacle
9 On/Off
switch
10 Knurled
screws
Technical specifications
Battery LED emitter
Brand: Powerfix
Model name:
PLS 10 A1
Operating voltage:
12 – 24 V
Rechargeable battery:
Rechargeable Li-Ion battery 7.4 V / 5200 mAh
Battery charging time:
approx. 6 hours
Runtime with fully charged battery
approx. 3 hours at around 80% of luminous flux
Power consumption
complete battery LED emitter:
approx. 10 W
Safety class:
(Extra Low Voltage, ELV)
Degree of protection
IP65
