Powerfix PLS 10 A1
24 - English
Replacing the fuse
If the 12/24 V car charger cable (C) is connected but the LED indicator of the 12/24 V car
charger cable (C) does not light, the fuse might be defective.
WARNING! If you need to replace the fuse, make sure to use a fuse
of the same type (see the Technical Specifications).
To replace the fuse, proceed as follows:
 Rotate the screw cap (d) counter-clockwise and remove it from the cigarette lighter plug
housing (a). If necessary, use a pliers.
 Replace the fuse (b) with a new fuse of the same type. You can purchase a suitable fuse
from any electronics retail outlet.
 First insert the fuse (b) into the cigarette lighter plug housing (a).
 Insert the metal contact (c) into the screw cap (d).
 Next insert the screw cap (d) with the inserted metal contact (c) over the fuse (b) and
then screw the cap (d) clockwise onto the cigarette lighter plug housing (a).
