English - 21
WARNING! Use the supplied wall plug battery charger (B) and the supplied
12/24 V car charger cable (C) to charge the buil-in battery of the battery LED
emitter (A) and never use it for continuous operation like a power adapter. Never
connect the wall plug battery charger (B) or the 12/24 V car charger cable (C) to
other devices. Charge the built-in battery of the battery LED emitter (A) with the
supplied wall plug battery charger (B) and the supplied 12/24 V car charger
cable (C).
Copyright
All the contents of this user manual are protected by copyright and provided to the reader
for information only. Copying data and information without the prior explicit written consent
of the author is strictly forbidden. This also applies to any commercial use of the contents and
information. All texts and diagrams are up-to-date as of the date of printing. Subject to
change without notice.
Before you start
Remove the battery LED emitter (A) and the accessories from the packaging.
Inspect the battery LED emitter (A) and the accessories for damage. If the battery LED emitter
(A) is damaged, do not use it.
Mounting
No tools are needed to mount the battery LED emitter (A). The battery LED emitter (A) is
delivered in two pieces (emitter with handle and stand). To start, you have to assemble them.
To do so, rotate the knurled screw (4) that secures the device for transport and is inserted on
the stand (5) counter-clockwise and remove it. Make sure not to lose the washer and the
retainer ring placed of the knurled screw (4) threaded pin. Next fold the mounting bracket
(3) downwards. Then insert the knurled screw (4) through the central bore hole of the
