Multi-Contact MA042 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
DBT-KBT16-NS KBT16BV-NS/M... KST16BV-NS/M... DST16-NS
H.../16BV-NS
H...-H07RN-F/16BV-NS
FIXBAND-B16BV
15.5832 FIXBAND-S16BV
15.5834
MA042 (de_en)
Montageanleitung MA042 (de_en)
Assembly instructions
Rundsteckverbinder
KBT16BV-NS/M...
KST16BV-NS/M...
mit Bajonettverriegelung Round connectors
KBT16BV-NS/M...
KST16BV-NS/M...
with bayonet locking
Inhalt
Sicherheitshinweise....................................................................2
Erforderliches Werkzeug ...........................................................3
Leitungskonfektionierung ..........................................................3
Vorbereitung der Leitung ...........................................................4
Montage ....................................................................................4
Austausch der Crimphülse oder der Leitung .............................6
Montage der Schutzkappe ........................................................6
Montage des Fixbandes ............................................................6
Prinzip der Bajonettverriegelung ...............................................8 Content
Safety Instructions ....................................................................2
Tools required ............................................................................3
Cable assembly .........................................................................3
Cable preparation ......................................................................4
Assembly ...................................................................................4
Replacement of a crimping sleeve or cable...............................6
Fitting the protective cap ...........................................................6
Assembly of the Fixband ...........................................................6
Bayonet locking system ............................................................8
Auswechselbarer Crimpanschluss
Replaceable crimp sleeve
