Multi-Contact MA047 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
IS10BV-C...
MS-S10BV
VK-S10BV
1) For assembly in front panel only
MA047 (de_en)
Montageanleitung MA047 (de_en)
Assembly instructions
Stecker IS10BV-C... mit Bajonnet-verriegelung
und Gewindeanschluss Plugs IS10BV-C... with bayonet locking and th-
readed stud
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
1. Montage in Stromschiene .....................................................3
2. Montage in Fronttafel ............................................................4
3. Montage des Mikroschalters (MS-S10BV) ............................5
Funktionskontrolle des Mikroschalters ......................................6
Verschlusskappe ........................................................................6
Kodierung ..................................................................................6
Wichtiger Hinweis .....................................................................7 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
1. Assembly into busbar ............................................................3
2. Assembly in front panel .........................................................4
3. Installation of microswitch (MS-S10BV) ................................5
Functional check of microswitch ..............................................6
Protective cap ............................................................................6
Coding .......................................................................................6
Important notice ........................................................................7
Dichtung 1)
Seal 1)
Mikroschalter
Mikroswitch
Verschlusskappe
Protective cap
1) Nur für Montage in Fronttafel
