Varyscan MICRO 150HTI
12
JB-lighting Lichtanlagentechnik GmbH Sallersteigweg 15 D-89134 Blaustein 07304-9617-0
1. Indroduction
1.1 General Remarks
The Varyscan MICRO 150HTI is equipped with 7 colours plus white, 10 gobos (two of
them interchangable), rainbow effect in different speeds and one high speed shutter.
The pan and tilt movement can opperate in 8bit or 16bit mode, depening on the lighting
control desk in use.
1.2 Unpacking
Open the top of the box and remove the unit with the inlays. Remove the
inlays from the Varyscan.
For any damage occuring during transport, report to the transport company
immediately.
arm
DIP switch
DMX connector
weight: 9.8 kg
power supply: 230V 50Hz
current consumption: 2A
lamp: OSRAM 150HTI
max.
ambient temperature:
50°C
JB-li
g
hting
1.3 Technical Datas
mains connection
Fuse
3.15AT
Base
