24
DEUTSCH
Index
v A
Anschluss
5.1-Mehrkanal-Wiedergabe······························ 17
Bi-Verkabelung ··················································· 8
Fernbedienungsanschlüsse ····························· 20
Kabel ·································································· 6
Lautsprecher ······················································ 8
Netzkabel ························································· 10
Player ································································· 9
Power Amp Direct ··········································· 19
PRE OUT-Anschlüsse ······································ 19
Recorder ·························································· 10
Vollständiger Stereo-Doppelverstärkermodus (Bi-
Amp) ································································ 16
Auswählen des Tonabnehmers: MM/MC ·········· 21
Automatischer Bereitschaftsmodus ··················· 20
v B
Batterien ······························································· 2
v E
Einlegen der Batterien ·········································· 2
Einstellen der Lautstärke ···································· 11
Einstellen der Pegel (links und rechts) ··············· 12
Einstellen des Klangs ········································· 12
v F
F.C.B.S.-Anschluss ············································· 14
Fernbedienung ····················································· 5
v H
Hohe Frequenzen ··············································· 12
v I
INPUT SELECTOR ·············································· 11
v K
Kabel
Lautsprecherkabel ············································· 6
Steckerkabel ······················································ 6
Symmetrisches Kabel ········································ 6
Kondensation ······················································· 2
v L
Lautsprecher-Impedanz ··································· 7,21
v S
Schutzschaltung ·············································· 7,21
Stummschalten des Tons ·································· 13
v T
Tiefe Frequenzen (Bässe) ··································· 12
v V
Vorderseite ··························································· 4
v Z
Zubehör ································································ 1
Technische Daten
• RMS Uitgangsvermogen:
(20 Hz - 20 kHz, gleichzeitige Ansteuerung
beider Kanäle)
100 W × 2 (8 Ω)
200 W × 2 (4 Ω)
• Totale harmonische vervorming:
(20 Hz - 20 kHz, gleichzeitige Ansteuerung
beider Kanäle, 8 Ω)
0,01 %
• Uitgangsbandbreedte: (8 Ω, 0,05 %)
5 Hz – 45 kHz
• Frequentiekarakteristiek:
(CD, 1 W, 8 Ω belasting)
5 Hz – 120 kHz ±3 dB
• Dämpfungsfaktor:
(8 Ω, 20 Hz − 20 kHz)
100
• Eingangsempfindlichkeit/Eingangsimpedanz
PHONO (MC):
260 µV / 100 Ω
PHONO (MM):
2,7 mV / 47 kΩ
BALANCED:
480 mV / 40 kΩ
CD/LINE:
240 mV / 20 kΩ
P. DIRECT IN:
1,7 V / 20 kΩ
• Ausgangsspannung/Ausgangsimpedanz
PRE OUT:
1,9 V / 220 Ω
• Maximaal toelaatbare PHONO ingang (1 kHz)
MC:
10 mV
MM:
105 mV
• RIAA-Abweichung (20 Hz−20 kHz):
±0,5 dB
• S/N (IHF-A, 8 Ω)
PHONO (MC):
76 dB (0,5 mV Eingang, 1 W Ausgang)
PHONO (MM):
88 dB (5 mV Eingang, 1 W Ausgang)
BALANCED:
109 dB (4 V Eingang, Nennausgang)
CD/LINE:
108 dB (2 V Eingang, Nennausgang)
• Klangregelung
BASS (50 Hz):
±8 dB
TREBLE (20 kHz):
±8 dB
• Netzspannung:
230 V Wechselstrom, 50/60 Hz
• Leistungsaufnahme (EN60065):
300 W
• Leistungsaufnahme im Bereitschaftsmodus:
0,2 W
Änderung der technischen Angaben und des Designs zum Zwecke der Verbesserung ohne
Ankündigung vorbehalten.
