Quadral AURUM ORKAN aktiv - Handbuch (Seite 5)

Technische Daten ORKAN aktiv ALTAN aktiv
Eingangsimpedanz (XLR) 47 kOhm 47 kOhm
Eingangsempfindlichkeit (XLR) 100mV/87dBSPL 100mV/85dBSPL
Eingangsimpedanz (Line) 33 kOhm 33 kOhm
Eingangsempfindlichkeit (Line) 100mV/87dB SPL 100mV/85dB SPL
Maximale Eingangsspannung
(XLR / RCA)
6V / 6 V 6V / 6 V
Ausgangleistung (Gesamt) 320 W 200 W
Harmonische Verzerrungen (Klirr) <0.05% <0.05%
Frequenzgang 28 Hz - 65.000 Hz 38 Hz - 65.000 Hz
Eingänge
Unsymmetrisch (Unbalanced) 1 x RCA 1 x RCA
Symmetrisch (Balanced) 1x XLR 1x XLR
Schutzschaltungen Temperatur, Überlast Temperatur, Überlast
Auto off (Stand by) nach: 15 Minuten ohne Signal 15 Minuten ohne Signal
Prinzip Druckkammer/Bassreflex Bassreflex
Bestückung
Maße in mm: Bass/ Mittelton /
Hochton 2 x 170 / 1 x 170 /
Bändchen
1 x 170 / -- /
Bändchen
Netzanschluss
100V/115V ~60Hz, 230V
~50Hz
100V/115V ~60Hz, 230V
~50Hz
Leistungsaufnahme
Normalbetrieb
14,3 W 10,6 W
Leistungsaufnahme
Vollaussteuerung
350 W 280 W
Stromaufnahme Stand by <0,2 W <0,2 W
Abmessungen
Höhe 1022 mm 405 mm
Breite 222 mm 222 mm
Tiefe 448 mm 345 mm
Gewicht 32640 g 14720 g
First of all we would like to thank you for your decision to purchase our AURUM active
speaker. We manufacture top-quality HiFi equipment in Germany that satisfies the
requirements of music lovers like you and the standard of our equipment is far above
the average. Even if you already know a lot about this type of equipment, we will
introduce some basic rules in the following that will enable you to get the best out
of your new product.
Safety instructions
Please read through these instructions carefully and follow all of the steps listed
here for installing the equipment. You must abide by all of the warnings and safety
instructions that are stipulated on the unit and in this instruction manual. Keep this
manual close to hand so that you can consult it if you have any questions later on.
• The mains power cable and other connecting cables must be laid so that none
of them are crushed or damaged by furniture, are being trodden on, and / or
that nobody will trip over them.
• Take the power plug out of the socket during lightening storms or if the equipment
will not be used for a long time. Always pull the plug out of the socket and never
remove it by pulling on the cable!
• The amplifier‘s speaker terminals must only be connected up to the relevant
inputs on the speakers. You must never connect these terminals up to the
electrical mains supply (230V / 115V) as this will destroy the equipment and all
interconnected units immediately. Therefore you must never fit plugs on these
cable connections to ensure that they can never be mixed up with mains plugs.
• Voltages above 30V can be present at the speaker terminals if high volume is
being used. Therefore you should never touch the terminals when the amplifier is
being used.
The lightening symbol inside an
equal-sided triangle is used to
warn you about the presence
of non-insulated components
carrying a dangerous, live
voltage that might cause severe
personal injuries. The exclamation mark inside an
equal-sided triangle indicates
that there is important information
available regarding the use and
maintenance of your equipment.
