Specifications ORKAN active ALTAN active
Input impedance (XLR) 47 kOhms 47 kOhms
Input sensitivity (XLR) 100mV / 87 dB SPL 100mV / 85 dB SPL
Input impedance (line) 33 K ohms 33 K ohms
Input sensitivity (line) 100mV / 87 dB SPL 100mV / 85 dB SPL
Maximum input voltage (XLR /
RCA)
6V / 6 V 6V / 6 V
Output power (overall) 320 W 200 W
Harmonic distortion (THD) <0.05% <0.05%
Frequency response 28 Hz – 65,000 Hz 38 Hz – 65,000 Hz
Inputs
Unbalanced 1 x RCA 1 x RCA
Balanced 1 x XLR 1 x XLR
Protection circuit Temperature, overload Temperature, overload
Auto off (stand-by) after: 15 minutes without a signal 15 minutes without a signal
Operating principle Press. chamber/bass reflex Bass reflex
Equipping
Sizes in mm: Bass/ mid-range /
tweeter 2 x 170 / 1 x 170 /
ribbons
1 x 170 / -- /
ribbons
Mains power connection
100V/115V ~60Hz; 230V
~50Hz
100V/115V ~60Hz, 230V
~50Hz
Power consumption in normal
mode
14.3 W 10.6 W
Power consumption at
maximum volume
350 W 280 W
Power consumption in stand-by
mode
<0.2 W <0.2 W
Dimensions
Height 1,022 mm 405 mm
Width 222 mm 222 mm
Depth 448 mm 345 mm
Weight 32,640 g 14,720 g
