ENGLISH
Notes about the removal and the correct
environmentally-friendly disposal of
old batteries
Notes about the removal and the correct environmentally-friendly disposal of old batteries
The symbol shown here can be found on the equipment‘s enclosure, the packaging as
well as in the documents or the operating manual. It tells you that batteries provided
with the equipment as well as those supplied with or fitted in other units must never be
disposed of in household waste. They must be disposed of in an environmentally-friendly
way (in compliance with the local regulations or European Directives 2002/96/EU and
2006/66/EU).
You should find out where the nearest collection point for electronic scrap is or where
the recycling site is. Correct disposal of the equipment and the batteries will help to
preserve our resources and prevent physical and environmental damage. The battery
(CR2025) supplied with the remote control contains lithium and it must be disposed of in
an environmentally-friendly way as described above.
Proceed as described in the following section to replace or remove the battery fitted in
the remote control.
You must ensure that the new battery‘s polarity is correct when you fit the new one! The
side of the battery marked with a ‘+’ sign / inscription must be pointing upwards when
it is fitted in the battery compartment!
Note:
BT (BLUETOOTH ® )
Sound reproduction will be automatic after the link to a transmitter has been established.
The link will remain set up even if the inputs are changed, provided that the transmitter
remains in range of the MAGIQUE or MAGIQUE XS and it has not been switched off.
11. MUTE – Press this button to “mute” the unit. Press the button once again to switch the
function off.
Display [MT] flashes
12. LEARN This button enables any of the buttons on your TV or DVD remote control to
be used for operating the MAGIQUE XS or MAGIQUE.
Programming example:
1. Press button 12 (LEARN) on the remote control RC-11.
2. Display [LR] flashes.
3. Press the button for the function that you want to learn (e.g. volume + button 9).
4. Display [LR] stops flashing.
5. Press the button on the TV/DVD remote control that you want to transfer this
function to.
6. Display [OK] appears
Programming the MAGIQUE XS or MAGIQUE to your TV / DVD remote control has
been completed. The respective remote control must be pointed at the IR receiver in your
MAGIQUE so that the programming can be undertaken. The programming will have
been unsuccessful if [FL] is displayed.
Repeat steps 1 to 6 again if this happens.
Ambient conditions
The remote control has a range of up to 6 m and works without any problems from
a radiating angle of up to 30° in relation to the front of the equipment. Dust on the
transmitter or dirt on the receiving sensor and operating it in the vicinity of fluorescent
lights might reduce the range. A direct line-of-sight connection between the transmitter
and the receiver is needed.
Push small tab forward battery
slot.
Insert battery with (+) side up, and
slide drawer back.
Remove battery.
+
